| Free Speed, RPM |
1,320 |
| Sound Pressure Level, dB(A) |
110 |
| Length, inches (mm) |
8.2 (208) |
| Air Consumption, Free Speed, CFM (SCFM) [l/min] |
3.4 (24) [95] |
| Recommended Air Pressure, PSIG (kPa) |
90 (620) |
| Replacement Chuck only |
AT803-2 |
| Air Inlet Thread Size, inches (NPT) |
1/4 (18) |
| Chuck Cap., inches (mm) |
3/8 (10) |
| Country Of Origin |
TWN |
| Sound Level dB(A) Pressure |
110 |
| Rated Power, HP (kW) |
0.45 (.33) |
| Torque Range, in-lb (N•m) |
0–55 (0–6) |
| Vibration Level, m/s² |
<.8 |
| Spindle Thread, inches |
3/8"-24 UNF |
| Recommended Hose Size, inches (mm) |
3/8 (10) ID min. |
| Horsepower, HP |
0.25 |
| Weight, lb (kg) |
2.2 (1) |
| Sound Level, dB(A) |
110 |
| Chuck Size, inches (mm) |
3/8 (10) |
| Air Consumption, Average, CFM (SCFM) [l/min] |
3.4 (24) [95] |
| Overall Length, inches (mm) |
8.2 (208) |
| Chuck Key |
AT811-36 |
